Full Computerized High Speed Vacuum Transfer Top Flexo Printing Slotting Die-cutting (RDC) Machine for Making all Kinds of Corrugated Carton Boxes Save Labor and Materials

GNERNAL FEATURS

1. Integrated CNC Control system, trouble shooting, production management system, remote control for maintenance, can connect with ERP system.
2. Quick printing plate mounting, motorized phase zero, register servo control.
3. Powerful dust remover, combined with 3-4 dust blowers, anti-static bar, anti-brushes.
4. High precision transfer structure with ceramic coated vacuum transfer wheels, good registration and accuracy.
5. With CE and National Patent Certificate, choose international first brand electric parts for stable running and durable using.

FLEXO PRINTER SLOTTER DIE-CUTTER RDC

Main Control System

Windows base CNC Control System

Remote maintenance

Huge order saving quantities

Trouble-shooting

Optimized order memory

Production and order management system

Can connect with ERP system

Feeding Unit

1. Operation can be controlled by both main computer and each unit touch screen.
2. Accurate and low pressure feeding, adjustable air control, precision registration.
3. Precision liner guideway lateral moving
4. Motorized side squaring and paper support
5. Powerful dust remover, combined with 3-4 dust blowers, anti-static bar, anti-brushes.

PRINTING SECTION

1. Operation can be controlled by both main computer and each unit touch screen.
2. Top print, high precision transfer structure with ceramic vacuum transfer wheels, good registration accuracy.
3. Quick printing plate mounting, register servo control, automatic back to zero position.
4. Ceramic Roller as standard, Chambered doctor blade as optional.
5. Ink saving circulation system, safety link taking, short ink alarm.
6. USA ARO ink pump.

SLOTTER CREASER SECTION

1. All the shafts are made of solid steel pipe, and all dynamically balanced and constructed in High quality steel, surface ground and hard chrome plating.
2. Friendly HMI touch screen interface and also push-button control to adjust the box height, panel size and axial movement easily.
3. All Creasing wheels are poly coated to protect the cardboard being damaged, and with Dual Creasing System, easy for 3-5-7 ply change.
4. All pairs of Pre-creasing, Creasing, Re-creasing, Slotting shafts are synchronous moving, with linear guiding combined with screw rod structure, smooth and stable and durable.

DIE CUTTER SECTION

1. Anvil cover Cylinder was independent control by Frequency motor, which speed can be adjusting.
2. Using direct servo drive system on die-cutting unit to effectively reduce the impact of die-cutting vibration and printing.
3. Heavy duty die cutting cylinder.
4. Die-cutting Register servo control.
5. With automatic grinding system for anvil cover.
6. Auto zero- set for die cutting position.

MAIN PARAMETERS

PRINTING PHOTO

CONTAINER LOADING PHOTO

Guangdong Toprint Machinery Co., Ltd (Short for Toprint) is a professional manufacturer of Carton Box Making
Machines, providing Flexo Printer Slotter Die-cutter Inline Folder Gluer & Counter Ejector and etc...

Toprint is located in Shishan Town, Nanhai District, Foshan City, a Pearl River Industrial Area with strong industrial
foundation and complete processing. We have accumulated a lot of experience and technology in the process of
production and serving customers, we are familiar with each industrial production process, takes this as the technical
basis, and the continuous investment on R & D, in line with the principle of Honesty & Pragmatism, Continuous
Innovation, Strengthening Management, Consummating Service, Quality First, Brand Oriented, to Serve the all
customers.

Toprint Main Products: Vacuum Transfer type Fully automatic Flexo Printer Slotter Die-cutter Auto Stacker; Fully
automatic flexo Printer Slotter Die-cutter Inline Folder Gluer & Counter Ejector; Optional for Dry-well Unit, Vamish
Unit, Servo Control Die-cutting Unit, Automatic Pre-feeder, Vibrator, Automatic Counter Stacker and other Carton
Related Machines, can also custom made according to customer's requirements.

Toprint seeks to develop together with customers, customer demand is our pursuit, and we will meet the needs of
customers with high-quality products and good service. Products carry out lifelong service, long-term supply of spare
parts and after-sales service and etc..

Service commitment: 48 hours arriving of emergency failure (domestic),reply within 8 hours of pre-sale and after-
sale consultation.

We make difference,Dedicated, Professional, Pay attentions on Each Machine!
We make difference, Honestly Toprint, let every Customer being satisfied!
We make difference,Pioneering and Innovative, Excelsior,GD.Toprint!
We make difference,CR CHR Series take us to create Brilliant!
